Image Dynamics IDMAX10 V4 10 inch Subwoofer
$429.99
Image Dynamics IDMAX10 V4 10 inch Subwoofer: a 10-inch subwoofer rated 500 watts RMS, offered in 0.9 ohms, 2 ohms, 4 ohms or dual 2 ohm.
Image Dynamics IDMAX10 V4 10 i...
$429.99
Image Dynamics IDMAX10 V4 10 inch Subwoofer: a 10-inch subwoofer rated 500 watts RMS, offered in 0.9 ohms, 2 ohms, 4 ohms or dual 2 ohm.
Published parameters: Fs 400 Hz, Qts 0.609, Vas 37.18 L, Xmax 27 mm. Those three numbers decide the box; the amplifier only decides how loud it gets.
The manufacturer recommends 2 cubic feet ported. We cut enclosures to those figures; ask if you want this driver boxed.
Pair the amplifier against RMS, not peak, and wire the voice coils to an impedance the amp is stable at.
Available as Dual 2 ohm or Dual 4 ohm; tell us which you want in the order notes.
Questions on fit or matching? Call or text (775) 541-2950 with your vehicle and the gear you are running.
Listed specifications
- Image Dynamics IDMAX10 V.4 10 Inch Subwoofer
- 500W RMS 1000W Peak 400 oz Motor 27 Hz Fs
- 27 Hz Resonant Freq
- 500W RMS Power
- 27 Hz Fs and Deep Bass Extension
- D2: Dual 2 Ohm | Qts 0.609 | Fs 27 Hz | Vas 37.18 L
- 51.4 Hz
- 38.2 Hz
- 44.8 Hz
- 35.0 Hz
