DD Audio 710g Ported Enclosure, Dual 10″

DD Audio 710g dual ported enclosure, 10-inch, with 3.03 cubic feet of net airspace tuned to 34 Hz through 65.2 square inches of port; the anechoic F3 is 29 Hz.

The port is tuned to 34 Hz. Expect a lift of several dB around that point relative to the same driver sealed, and run a subsonic filter 5 to 10 Hz below it; under tuning the port stops loading the cone.

65.2 square inches of port area keeps air velocity down at high output, so the port does not chuff when the music gets loud.

Polyfill pre-installed.

The drivers share one chamber, so run matching drivers wired to the same impedance. If you are between two drivers, send both model numbers and we will tell you which one this volume suits.

Questions on fit or matching? Call or text (775) 541-2950 with your vehicle and the gear you are running.

Specifications

• Enclosure type: Ported
• Drivers: Dual, 10-inch
• Net volume: 3.03 cu ft
• Tuning: 34 Hz
• Port area: 65.2 sq in
• F3 (anechoic): 29 Hz
• Height: 20.5 in
• Width: 35 in
• Depth: 20.5 in
• Front baffle: Double layer, 1.5 in
• Chambers: Shared
• Fits: DD Audio 710g
